Detail
| Model | G177F | G188F | G190F | G192Q |
| Engine | Gasoline | Gasoline | Gasoline | Gasoline |
| Engine model | 177F | 188F | 190F | 192F |
| Engine type | 1 cylinder, 4 stroke, air-cooled | |||
| Power | 9HP | 13HP | 15HP | 16HP |
| Speed | 3600r/min | 3600r/min | 3600r/min | 3600r/min |
| Starting Mode | Manual /Electric start | |||
| Fuel Capacity | 6 L | 6 L | 6.5L | 6.5L |
| Oil Capacity | 1.1L | 1.1L | 1.1L | 1.1L |
| Clutch style | Plate clutch | |||
| Type of drive | Gear drive | |||
| Gear shift | 2 0 1 R | |||
| Cultivation width | 1000mm | 1350mm | 1350mm | 1350mm |
| Cultivation depth | 10-25mm | 10-25mm | 10-25mm | 10-25cm |
| Working efficiency | 1-1.6km/h | 1-1.6km/h | 1-1.6km/h | 1-1.6km/h |
| Productivity | 0.035-0.08hm²/h | 0.035-0.08hm²/h | 0.035-0.08hm²/h | 0.05-0.1hm²/h |
| Oil consumption | 12-15kg/hm² | 12-15kg/hm² | 12-15kg/hm² | 10-15kg/hm² |
| N.W. | 115kg | 115kg | 120kg | 120kg |
| G.W | 125kg | 125kg | 130kg | 130kg |
| Packing size | 95*55*77 | 95*55*77 | 95*55*77 | 95*55*77 |
| Loading Quantity (20/40HQ) | 72/144 | 72/144 | 72/144 | 72/144 |
