Detail
| Model | D1350E | D1050E | D950E |
| Engine | Diesel | Diesel | Diesel |
| Engine model | 186FAE | 178FE | 173FE |
| Engine type | 1 cylinder, 4 stroke, air-cooled | ||
| Power | 9HP | 6HP | 5HP |
| Speed | 3600r/min | 3600r/min | 3600r/min |
| Starting Mode | recoil/electric | ||
| Fuel Capacity | 5.5L | 3.5L | 2.5L |
| Oil Capacity | 1.6L | 1.1L | 0.75L |
| Clutch style | Plate clutch | ||
| Type of drive | Gear drive | ||
| Gear shift | 2 0 1 R | ||
| Cultivation width | 1350cm | 1350cm | 1000mm |
| Cultivation depth | 10-25cm | 10-25cm | 10-25mm |
| Working efficiency | 1-1.6km/h | 1-1.6km/h | 1-1.6km/h |
| Productivity | 0.05-0.1hm²/h | 0.05-0.1hm²/h | 0.035-0.08hm²/h |
| Oil consumption | 10-15kg/hm² | 10-15kg/hm² | 12-15kg/hm² |
| N.W. | 140kg | 130kg | 100kg |
| G.W | 150kg | 140kg | 110kg |
| Packing size | 95*55*78 cm | 95*55*78 cm | 85*45*77 |
| Loading Quantity (20/40HQ) | 72/144 | 72/144 | 90/210 |
